S7-200 SMART Digital Output EM DR16, 16 DO, Relay
Description
SIMATIC S7-200 SMART EM DR16 Digital Output Module (Relay)
❝AVAILABLE MODELS❞
Part Number: 6ES7288-2QR16-0AA0
Type: Expansion Module (Digital Output – Relay)
Product Name: EM DR16
❝PRODUCT DETAILS❞
➜ EM DR16 is a digital output expansion module designed for SIMATIC S7-200 SMART PLC systems, used to increase relay output capacity in industrial automation applications.
➜ It provides 16 relay outputs, allowing flexible switching of AC/DC loads such as contactors, solenoids, alarms, and indicator devices.
➜ The module is suitable for applications requiring isolated outputs with reliable electromechanical switching.
➜ It integrates seamlessly with S7-200 SMART CPUs, enabling scalable system expansion for machine and process automation.
❝KEY SPECIFICATIONS❞
➜ Part Number: 6ES7288-2QR16-0AA0
➜ System: S7-200 SMART
➜ Module Type: Digital Output Expansion Module
➜ Outputs: 16 DO (Relay Type)
➜ Output Isolation: Relay Contacts
➜ Supports AC/DC Load Switching
➜ High-Density Output Module
➜ Compact Modular Design
➜ Reliable Industrial Switching
➜ Easy Plug-in Expansion
➜ STEP 7 Micro/WIN SMART Compatible
❝PRODUCT APPLICATIONS❞
➜ Machine Automation Systems
➜ Conveyor Systems
➜ Packaging Machinery
➜ Textile Machines
➜ Pump & Compressor Systems
➜ HVAC Automation
➜ OEM Machinery
➜ Industrial Control Panels
➜ Material Handling Systems
➜ Production Line Automation
➜ Utility Automation Systems
➜ General Industrial Switching Applications
❝PRODUCT❞
➜ 6ES7288-2QR16-0AA0 – EM DR16 Relay Output Module
➜ S7-200 SMART CPU Series (SR/CR Models)
➜ Siemens HMI SMART Panels
➜ Relays, Contactors & Field Devices
➜ Sensors & Industrial Drives
➜ Automation Systems
❝CONTACT❞
➜ Supplier / OEM Stockist: Scalar Automation
➜ Location: Ahmedabad, Gujarat, India
Specifications
| MODEL NUMBER | DESCRIPTION |
|---|---|
| 6ES7288-2QR16-0AA0 | Digital Output EM DR16, 16 DO, Relay |
