6ES7334-0KE00-0AB0
Description
6ES7334-0KE00-0AB0
SIMATIC S7-300 SM 334 Analog Module — Spare Part
➜ BRAND: SIEMENS
❝PRODUCT DETAILS❞
➜ 6ES7334-0KE00-0AB0 is a SIMATIC S7-300 SM 334 analog module, supplied as a spare part for compatible S7-300 automation systems.
➜ The module combines 4 analog inputs (AI) and 2 analog outputs (AO) in a single module, providing both analog signal acquisition and signal output capabilities.
➜ It provides 12-bit resolution for analog measurement and control applications.
➜ The module supports 0–10 V signals and includes Pt100 measurement with a specified climatic temperature range of −120 to +155 °C.
➜ It also supports a 10 kOhm measuring range, providing additional flexibility for resistance-based measurement applications.
➜ The module features isolated channels and uses a 1 × 20-pole connection for field wiring and integration into the SIMATIC S7-300 system.
❝SPECIFICATIONS❞
➜ Part Number: 6ES7334-0KE00-0AB0
➜ Product Type: SIMATIC S7-300 Analog Module
➜ Module Type: SM 334
➜ Product Status: Spare Part
➜ Analog Inputs: 4 AI
➜ Analog Outputs: 2 AO
➜ Resolution: 12 bit
➜ Signal Range: 0–10 V
➜ Temperature Measurement: Pt100
➜ Pt100 Climatic Range: −120 to +155 °C
➜ Resistance Measuring Range: 10 kOhm
➜ Isolation: Isolated
➜ Connection: 1 × 20-pole
➜ Product Series: SIMATIC S7-300
➜ Application: Analog Signal Acquisition, Pt100 Temperature Measurement, Resistance Measurement, Analog Control and Industrial Automation
❝CONTACT❞
➜ Supplier / OEM Stockist: Scalar Automation
➜ Location: Ahmedabad, Gujarat, India
Specifications
| MODEL NUMBER | 6ES7334-0KE00-0AB0 |
|---|---|
| DESCRIPTION | SM334, 4AI/2AO, 0-10V f.PT100 |
