6ES7131-6BF00-0CA0
Description
6ES7131-6BF00-0CA0
➜ BRAND: SIEMENS
❝PRODUCT DETAILS❞
➜ 6ES7131-6BF00-0CA0 is the SIMATIC ET 200SP Digital Input Module DI 8x 24 V DC High Feature, designed for high-performance digital signal acquisition in distributed automation systems.
➜ The DI 8x 24 V DC High Feature Module provides 8 digital inputs with 24 V DC voltage, supporting IEC 61131 Type 3 input characteristics and PNP (sink input) configuration for reliable connection of sensors, switches, and field devices.
➜ Featuring advanced channel diagnostics for encoder power supply short circuit, wire break, supply voltage monitoring, and channel faults, the module ensures reliable operation, easy troubleshooting, and improved system availability.
➜ Designed for seamless integration with SIMATIC ET 200SP systems, TIA Portal, PROFINET networks, HMIs, and SCADA systems, this module provides a compact and flexible solution for OEM machinery, control panels, and factory automation applications.
❝SPECIFICATIONS❞
➜ Part Number: 6ES7131-6BF00-0CA0
➜ Product Type: SIMATIC ET 200SP Digital Input Module
➜ Module Type: DI 8x 24 V DC High Feature
➜ Digital Inputs: 8 × DI
➜ Input Voltage: 24 V DC
➜ Input Type: Type 3 (IEC 61131)
➜ Input Configuration: PNP / Sink Input
➜ Input Delay: 0.05 to 20 ms
➜ Base Unit Compatibility: BU Type A0
➜ Color Code: CC01
➜ Diagnostics:
Encoder Power Supply Short Circuit
Wire Break Detection
Supply Voltage Monitoring
Channel Fault LED
➜ Packing Unit: 1 Unit
➜ Engineering Software: TIA Portal
❝COMPATIBLE PRODUCTS❞
➜ Siemens SIMATIC ET 200SP Distributed I/O System
➜ Siemens SIMATIC S7-1200 PLC Systems
➜ Siemens SIMATIC S7-1500 PLC Systems
➜ Siemens HMI Panels
➜ Siemens SCADA (WinCC)
➜ PROFINET Networks
➜ Industrial Ethernet Networks
➜ Sensors and Field Devices
➜ TIA Portal Engineering Software
➜ Machine Automation Systems
➜ Process Automation Systems
❝CONTACT❞
➜ Supplier / OEM Stockist: Scalar Automation
➜ Location: Ahmedabad, Gujarat, India
Specifications
| MODEL NUMBER | DESCRIPTION |
|---|---|
| 6ES7131-6BF00-0CA0 | ET 200SP, DI 8x24VDC HF, PU 1 |
