SIMATIC S7-1200 G2 Analog Modules
Description
SIMATIC S7-1200 G2 Analog Modules
❝AVAILABLE MODELS❞
Product Series: SIMATIC S7-1200 G2
Type: Analog Signal Modules (AI / AO / RTD / TC)
Brand: Siemens
❝PRODUCT DETAILS❞
➜ SIMATIC S7-1200 G2 Analog Modules are designed to extend the CPU’s capability for handling real-world process signals such as temperature, pressure, flow, level, and speed control signals.
➜ These modules convert analog field signals into digital values for PLC processing and generate analog outputs for control of actuators and drives.
➜ They are fully integrated into the TIA Portal engineering environment, enabling easy configuration, scaling, and diagnostics.
➜ The modules are widely used in machine automation and process control systems requiring precise measurement and control.
❝KEY FEATURES❞
➜ High-resolution analog signal acquisition (typically 14-bit class)
➜ Supports voltage and current inputs (e.g., 0–10V, ±10V, 4–20 mA)
➜ Analog output generation for control applications
➜ RTD and thermocouple temperature measurement support
➜ Fast conversion and stable signal processing
➜ Advanced diagnostics (wire break, overflow detection)
➜ Seamless integration with S7-1200 G2 CPUs
➜ Compact DIN-rail modular design
➜ Flexible channel configurations (AI / AO / mixed modules)
➜ Industrial-grade accuracy and noise immunity
❝PRODUCT APPLICATIONS❞
➜ Temperature monitoring systems
➜ Process automation systems
➜ Pump and compressor control
➜ HVAC systems
➜ Plastic injection machines
➜ Food and beverage processing
➜ Chemical and pharmaceutical systems
➜ Packaging machinery
➜ Energy and utility automation
➜ OEM industrial equipment
➜ SCADA-connected control systems
➜ Factory automation solutions
❝PRODUCT❞
➜ 6ES7231-4HF50-0XB0 SM 1231 Analog Input, 8AI
➜ 6ES7232-4HF50-0XB0 SM 1232 Analog Output, 8AQ
➜ 6ES7233-4HF50-0XB0 SM 1233 Analog I/O, 4AI/4AQ
➜ 6ES7221-3BF50-0XB0 SB 1221 Signal Board, 8DI 24VDC 100kHz
➜ 6ES7222-5BF50-0XB0 SB 1222 Signal Board, 8DQ 24VDC 100kHz
➜ 6ES7223-7AF50-0XB0 SB 1223 Signal Board, 4DI/4DQ 5V 200kHz
➜ 6ES7223-7BF50-0XB0 SB 1223 Signal Board, 4DI/4DQ 24V 100kHz
➜ 6ES7231-4HD50-0XB0 SB 1231 Signal Board, 4AI
➜ 6ES7232-4HD50-0XB0 SB 1232 Signal Board , 4AQ
➜ 6ES7233-4HD50-0XB0 SB 1233 Analog I/O, 2AI/2AQ
❝CONTACT❞
➜ Supplier / OEM Stockist: Scalar Automation
➜ Location: Ahmedabad, Gujarat, India
Specifications
| MODEL NUMBER | DESCRIPTION |
|---|---|
| 6ES7231-4HD50-0XB0 | SB 1231 Signal Board, 4AI |
| 6ES7233-4HF50-0XB0 | SM 1233 Analog I/O, 4AI/4AQ |
| 6ES7233-4HD50-0XB0 | SB 1233 Analog I/O, 2AI/2AQ |
| 6ES7232-4HF50-0XB0 | SM 1232 Analog Output, 8AQ |
| 6ES7232-4HD50-0XB0 | SB 1232 Signal Board , 4AQ |
| 6ES7221-3BF50-0XB0 | SB 1221 Signal Board, 8DI 24VDC 100kHz |
| 6ES7223-7BF50-0XB0 | SB 1223 Signal Board, 4DI/4DQ 24V 100kHz |
| 6ES7223-7AF50-0XB0 | SB 1223 Signal Board, 4DI/4DQ 5V 200kHz |
| 6ES7222-5BF50-0XB0 | SB 1222 Signal Board, 8DQ 24VDC 100kHz |
| 6ES7231-4HF50-0XB0 | SM 1231 Analog Input, 8AI |
