Signal Board SB 1223, 2DI/2DQ 24V 200KHz
Description
SIMATIC S7-1200 SB 1223 Signal Board
❝AVAILABLE MODELS❞
Part Number: 6ES7223-3BD30-0XB0
Type: Signal Board (Digital I/O Expansion)
Brand: Siemens
❝PRODUCT DETAILS❞
➜ SIMATIC S7-1200 SB 1223 is a compact signal board designed to expand both digital input and output capability directly on S7-1200 CPUs.
➜ It is used for space-saving I/O expansion in high-speed automation applications where fast signal processing is required.
➜ The module supports 24V DC high-speed digital signals suitable for fast switching and pulse-based control applications.
➜ It integrates directly into the CPU front and is configured using TIA Portal engineering software.
❝KEY SPECIFICATIONS❞
➜ Part Number: 6ES7223-3BD30-0XB0
➜ System: SIMATIC S7-1200
➜ Module Type: Signal Board (Digital I/O)
➜ Digital Inputs: 2 DI
➜ Digital Outputs: 2 DQ
➜ Input Voltage: 24V DC
➜ High-speed capability up to 200 kHz
➜ Compact CPU-mounted plug-in design
➜ Fast response time
➜ Industrial-grade reliability
➜ TIA Portal compatible
➜ Space-saving expansion solution
❝PRODUCT APPLICATIONS❞
➜ High-speed counting applications
➜ Encoder-based control systems
➜ Motion control systems
➜ Conveyor speed monitoring
➜ Packaging machinery
➜ Textile machines
➜ Precision automation systems
➜ OEM machine control systems
➜ Compact industrial control panels
➜ Fast signal switching applications
❝PRODUCT❞
➜ 6ES7223-3BD30-0XB0 – SB 1223 Signal Board (2DI/2DQ, 24V, 200 kHz)
➜ S7-1200 CPU series (1211C / 1212C / 1214C / 1215C etc.)
❝CONTACT❞
➜ Supplier / OEM Stockist: Scalar Automation
➜ Location: Ahmedabad, Gujarat, India
Specifications
| MODEL NUMBER | DESCRIPTION |
|---|---|
| 6ES7223-3BD30-0XB0 | Signal Board SB 1223, 2DI/2DQ 24V 200KHz |
