6ES7223-5PH50-0XB0
Description
6ES7223-5PH50-0XB0
➜ BRAND: SIEMENS
❝PRODUCT DETAILS❞
➜ 6ES7223-5PH50-0XB0 is the SIMATIC S7-1200 G2 SM 1223 Digital I/O Module, designed to expand Siemens S7-1200 G2 PLCs with 8 digital inputs and 8 relay digital outputs for reliable machine automation and process control applications.
➜ The SM 1223 Digital I/O Module provides 8 × 24 V DC digital inputs (sink/source) and 8 × relay digital outputs, each rated at 2 A, enabling dependable control of contactors, solenoid valves, indicator lamps, motors, and other industrial AC/DC loads.
➜ Designed for seamless integration with SIMATIC S7-1200 G2 PLCs, TIA Portal, HMIs, SCADA systems, and Industrial Ethernet networks, the module delivers reliable performance for OEM machinery, industrial control panels, and factory automation systems.
❝SPECIFICATIONS❞
➜ Part Number: 6ES7223-5PH50-0XB0
➜ Module Type: SM 1223 Digital I/O Module
➜ Digital Inputs: 8 × DI (24 V DC Sink/Source)
➜ Digital Outputs: 8 × Relay Outputs
➜ Switching Capacity: 2 A per Relay Output
➜ PLC Series: SIMATIC S7-1200 G2
➜ Engineering Software: TIA Portal
❝COMPATIBLE PRODUCTS❞
➜ Siemens SIMATIC S7-1200 G2 PLC
➜ Siemens HMI
➜ Siemens SCADA (WinCC)
➜ ET 200 Remote I/O
➜ Industrial PCs (IPC)
➜ PROFINET Networks
➜ Industrial Ethernet Networks
➜ TIA Portal Engineering Software
➜ Machine Automation Systems
➜ Process Automation Systems
❝CONTACT❞
➜ Supplier / OEM Stockist: Scalar Automation
➜ Location: Ahmedabad, Gujarat, India
Specifications
| MODEL NUMBER | DESCRIPTION |
|---|---|
| 6ES7223-5PH50-0XB0 | SIMATIC S7-1200 G2: SM 1223 digital I/O, 8 DI/8 RLY; inputs: 8x DI 24 V DC sink/source; outputs: 8x DO relay 2 A |
