SIEMENS 6ES7134-4NB01-0AB0 AVAILABLE IN SILVASSA

SIEMENS 6ES7134-4NB01-0AB0 AVAILABLE IN SILVASSA

SCALAR AUTOMATION is a trusted supplier and dealer of Siemens automation products serving Silvassa, Dadra and Nagar Haveli and industrial customers across India. We supply Siemens SIMATIC ET 200S modules, analog input modules, interface modules, PLCs, HMIs, VFDs, Servo Drives, SITOP power supplies, PROFIBUS products and industrial automation components for OEMs, machine builders, panel manufacturers, system integrators and industrial automation projects.

◇ SIEMENS 6ES7134-4NB01-0AB0 – SIMATIC DP ET 200S 2AI TC HIGH FEATURE

● Model: 6ES7134-4NB01-0AB0

● Product: SIMATIC DP Electronics Module for ET 200S

● Spare part

● Module type: 2AI TC High Feature

● Number of analog inputs: 2

● Module width: 15 mm

● Resolution: 15 bits + sign

● Input measurement: Thermocouple or voltage measurement

● Voltage input range: ±80 mV

● Thermocouple types: E, N, J, K, L, S, R, B, T and C

● Internal temperature compensation supported

● Internal reference junction possible with compatible ET 200S terminal modules

● Sensor characteristic curve linearization

● Isolated from load voltage L+

● Rated load voltage: 24 V DC from power module

● Reverse polarity protection: Yes

● Permissible common-mode voltage: 140 V DC / 100 V AC

● Electrical isolation between channels and backplane bus

● Electrical isolation between channels and load voltage L+

● Address space: 4 bytes

● Parameter length: 4 bytes

● Maximum shielded cable length: 50 m

● Current consumption from load voltage L+: max. 30 mA

● Typical power dissipation: 0.6 W

● Supports diagnostic functions

● SF red LED for group error indication

● Integrative measuring principle

● Resolution: 15 bits + sign

● 50 Hz / 60 Hz interference frequency suppression

● Basic conversion time including integration: approximately 66 ms at 60 Hz / 80 ms at 50 Hz

● Cycle time depends on number of active channels

● Operational limit for ±80 mV: ±0.1%

● Thermocouple operational limit: ±1.5 K

● Type C thermocouple operational limit: ±7 K

● Basic error limit for ±80 mV: ±0.05%

● Thermocouple basic error limit: ±1 K

● Linearization according to IEC 584 for supported thermocouple types

● Digital filtering / measured-value smoothing available

● Smoothing can be parameterized in four steps

● Temperature unit selectable as Celsius or Fahrenheit

● Wire-break diagnostics available for thermocouple measurement

● Suitable for SIMATIC ET 200S distributed I/O systems

● Suitable for industrial temperature measurement applications

● Suitable for process monitoring and process automation

● Suitable for machine automation and factory automation

● Suitable for OEM, panel builder and system integration applications

Siemens documentation identifies the 6ES7134-4NB01-0AB0 as the ET 200S 2AI TC HF analog electronic module, with two thermocouple/voltage inputs, 15-bit + sign resolution, ±80 mV voltage measurement, multiple thermocouple types, internal temperature compensation capability and 15 mm module width.

◇ SIEMENS ET 200S ANALOG INPUT MODULE SUPPLIER IN SILVASSA

SCALAR AUTOMATION supplies Siemens SIMATIC ET 200S analog input modules, 2AI TC modules, High Feature analog modules, temperature measurement modules and Siemens automation spare parts across Silvassa, Dadra and Nagar Haveli and surrounding industrial areas.

For Siemens 6ES7134-4NB01-0AB0 requirements, SCALAR AUTOMATION supports OEMs, machine manufacturers, panel builders, system integrators, maintenance teams, engineering companies, process industries and industrial automation users.

◇ SIEMENS 2AI TC HIGH FEATURE SUPPLIER IN SILVASSA

SCALAR AUTOMATION is a Siemens automation products supplier serving Silvassa, Dungra, Piparia, Amli, Masat, Rakholi, Khadoli, Naroli, Vapi, Sarigam, Umbergaon, Valsad, Pardi, Daman and surrounding industrial areas.

We support requirements for Siemens 6ES7134-4NB01-0AB0 2AI TC High Feature analog input module and other Siemens ET 200S products for temperature measurement, thermocouple input, analog signal processing, distributed I/O, process automation, machine control and industrial communication applications.
